Fault Injection Into Google Cloud Platform

This guide will walk you through injecting network faults into Google Cloud Platform Cloud Run. You will not need to change any code.

Prerequisites

Inject Latency Into a Cloud Run Service

  • Create a basic Cloud Run service

    You may want to follow the official GCP documentation to deploy a sample service.

  • Upload the fault container image to a GCP artifactory

    Cloud Run will expect the fault image to be pulled from an artifactory in the same region (or a global one). So this means, you must upload the official fault image to your own artifactory repository.

    Follow the official documentation to upload the fault image

    Something along the lines:

    # locally download the official fault image
docker pull ghcr.io/rebound-how/fault:<version>

# tag it to match your nex GCP Artifactory repository
docker tag ghcr.io/rebound-how/fault:<version> <region>-docker.pkg.dev/<project>/<repository>/fault:<version>

# push it to the repository
docker push <region>-docker.pkg.dev/<project>/<repository>/fault:<version>

  • Inject fault into the nginx service

    The following injects a 800ms into the service response time.

    fault inject gcp \
    --project <project> \  # (1)!
    --region <region>  \  # (2)!
    --service <service> \  # (3)!
    --image <image> \  # (4)!
    --duration 30s \  # (5)!
    --with-latency --latency-mean 800
    1. The GCP project where your CloudRun service is running
    2. The GCP region where your CloudRun service is running
    3. The GCP CloudRun service name
    4. The fault container image full url
    5. Optional duration after which the injection rollbacks. If unset, the user input is expected

    When you do not explicitly set the service, fault lets you pick up one from the CLI:

    fault inject gcp \
    --project <project> \
    --region <region>  \
    --image <image> \
    --with-latency --latency-mean 800
? Service:
> hello
[↑↓ to move, enter to select, type to filter]

    Once started, a new revision of the service will be deployed with the fault process running as a sidecar container of the service's main container. It will expose a port to receive traffic and route it to the application.
